Currently PTP 071H

The construction will consist of support pillars made of steel pipe with a diameter of at least 76 mm, minimum thickness - 3 mm. The floor must be made of HDPE - high-density polyethylene without toxic components with a multilayer structure of various colors with a thickness of at least 15 mm. The roof must be made of HDPE - high-density polyethylene without toxic components with a multilayer structure of various colors, with a thickness of not less than 10 mm. The side walls need to be made of HDPE - high-density polyethylene without toxic components with a multilayer structure of various colors, with a thickness of not less than 15 mm. The muzzle of the train must be in the form of a tube and must be made of HDPE with a thickness of not less than 10 mm. The wheels of the train (4 pcs on each side) must be made of HDPE with a thickness of not less than 10 mm.

The metal elements need to be sandblasted and painted in an electrostatic field, in two layers with a minimum thickness of 100 microns to give them resistance to the external environment.

Materials: HDPE, metal pipes covered with powder paint, all connections are covered with special anti-vandal caps.

Age: It is recommended for children aged between 3 and 6 years.

Dimensions: Length: 2180 mm, Width: 870 mm, Height: 1570 mm.

Download DWG drawing
